      WIKA mobile control provides various precise and reliable sensors for mobile mechanical control system.By using of MEMS and Hall technology, our products could be kept good output accuracy. The products use special anti-rusty materials and sealing technology to ensure normal operation in harsh environments. WIKA sensors can provide different types of electrical and communication interfaces, so as to make the system Integration flexible and safe.

 ●High reliability

 ●Easy to mark and calibrate

 ●Built-in digital amplifier with highprecision

 ●Applicable to harsh environment

 ●Safety level up to PLd

        WIKAmobile control force sensor is used to measure dynamic and static loads,collect and record shear force, tension and pressure, etc. The application areacovers the measuring force of cranes and winches, traction force measurement ofvehicles and ships, forklift load measurement; load measurement and collectionof frame conveyor, bridge crane and gantry crane, etc.

        WIKA mobilecontrol is strictly controlled in every process of design, production,measuring equipment, testing methods, specifications and could ensure theaccuracy and stability of sensor measurement.







Technical parameter

item

KMD

MA

DKA



Measuring range

10~16000kN

10~5000kN

10~3000kN

Accuracy *

＜0.3% FS

＜0.5～1%FS

＜0.3% FS

working temperature

-40~ +85℃

Protection level (IEC60529)（IEC60529）

IP66/IP67

working voltage

10~30V DC

Current consumption

＜50 mA (incl. amplifier)

output signal

4…20 mA,CANopen, CANopen Safety, 2.5…7.5V DC

Safety overload

（150%）200% of nominal load

Measuring body plastic change point

（200%）300% of nominal load

Fracture point *

（300%）500% of nominal load

Temperature drift

0.1%/10K

0.1%/10K

0.1%/10K

Linear error *

＜0.3% FS

＜0.5～1%FS

＜0.3% FS

Lag error *

＜0.5% FS

＜1%FS

＜0.5% FS

connector *

M12 or CANNON

M12 or CANNON

M12 or CANNON

Material

Stainless steel

Stainless steel

Stainless steel

Climate test

EN60068-2-30,DB55℃/100%

Shockproof

EN60068-2-6, 5-500Hz,50g,10min

Anti shock

EN60068-2-27(half sine)

50g,11ms,1000shocks, 1000g,1ms,50shocks

EN13849-1

Customizable PL,MTTFd and DC


Qualification certification
